Industrial Wastewater

Industrial Wastewater treatment technology

Although the conventional methods like, coagulation / flocculation, sedimentation, filtration, and disinfection are promising for the industrial waste water treatment, some of the chemical pollutants cannot be eliminated using such methods, hence the need to use integrated advanced treatment process technologies. The task of selecting the best treatment option for remedying specific industrial water is usually a complex one. EIS conduct pilot-plant studies at the client facility and such studies prove decisive in cases where several technologies are to be combined for reuse or decontamination of particular industrial spent water. EIS selection of the specific wastewater technology to apply include the quality of spent water, conventional treatment options, removal of contaminants, treatment flexibility, economic studies, the facility decontamination capacity, treatment system efficiency, reuse of treated water and the compatibility of wastewater treatment technology.

Currently, Electro coagulation (EC) and advanced oxidation processes (AOPs) are among the most frequently used approaches to remove pollutants that have low biodegradability or high chemical stability. These methods is depend on the generation of hydroxyl free radical (HO*) as a strong oxidant for the destruction of compounds which cannot be oxidized using conventional oxidants. Hydroxyl radicals, which are non-selective reactive species, able to oxidize pollutants into mineral end-products, yielding CO2 and inorganic ions.

The following well documented lab and field tested results are routinely attained through our electrocoagulation + AOP based effluent treatment plants.




Pollutants



% Removal

BOD

90 +

TSS (Clay, Coal, Silt, etc.)

99 +

Fats, oil and Grease in Water

93 - 99 +

Water in sludge

50 - 80 +

Heavy Metal Removal

95 - 99 +

Phosphate Removal

93 +

Bacteria, Viruses & Cysts

99.99 +

SPECIFIC EXAMPLES


Contaminant

Source

Raw mg/L

Treated

% Removal

Aluminum

Can Mfg.

224.00

0.690

99.70 % +

Arsenic

Steam Cleaner

0.30

<0.010

96.70 % +

Barium

Steam Cleaner

8.00

<0.100

98.70 % +

Calcium

Cooling Tower

1,321.00

21.400

98.40 %

Cadmium

Electroplating

31.00

0.340

98.90 %

Chromium

Condenser Wash

139.00

<0.100

99.90 % +

Cobalt

Steam Cleaner

0.13

<0.050

62.00 % +

Copper

Electroplating

287.00

0.480

99.80 %

Iron

Acid Mine

151.00

0.570

99.60 %

Lead

Manufacturing

8.21

0.230

97.20 %

Magnesium

Ammunition Plt.

6.40

<0.100

98.50 %

Magnesium

Ammunition Plt.

0.29

0.050

83.20 %

Mercury

Steam Cleaner

0.01

<0.002

66.60 % +

Molybdenum

Steam Cleaner

0.18

0.040

80.60 %

Nickel

Manufacturing

185.00

0.200

99.90 %

Silicon

Acid Mine

21.70

0.100

99.50 %

Vanadium

Steam Cleaner

0.23

<0.010

95.60 % +

Zinc

Plating

221.00

0.140

99.90 %

BOD

Fish Process

40,500.00

750.000

98.10 %

TSS

Municipal POTW

5,620.00

25.000

99.60 %

FOG

Food Process

18,165.00

28.000

99.90 % +

Bacteria

Municipal POTW

110MM

2,200.000

99.99 % +
